Design and Development of a Flexible
Manufacturing System
Talha Arif1, Parvez Alam2, Sanjeev Kumar Sarswat3
1, 3
Vivekananda College of Technology & Management, Aligarh-202001, Dr. A.P.J Abdul kalam Technical University, Lucknow-UP,
India
2
IET Department of mechanical University, GLA University, Mathura 281406, India
Abstract: In most organizations, a flexible manufacturing system (FMS) is concerned with the automatic production of different
parts in the middle range because it is flexible. In a nutshell, it's a machine that makes everything. FMS relies heavily on the
flow of jobs and tools in order to function. The FMS work centre can handle a large number of tasks at once. For FMS
facilities, a tool magazine is in use as a means of reducing tool inventory. We present the Jaya method in this work to schedule
tasks and tools simultaneously without considering tool transfer delays across machines; this is what we call the make span goal.
On numerous make span-related challenges, the suggested heuristic is evaluated and compared with current approaches. The
suggested heuristic beats the already used approaches, according to the findings.
Keywords: “Flexible Manufacturing System”, “Automation” performance, Manufacturing, flexibility
I. INTRODUCTION
There is a lot of competition in the global market, which means that businesses must be extremely flexible in their production in
order to meet the demands of their customers. More advanced products require the use of more complex manufacturing systems,
which makes it more difficult to comprehend how they are made. FMS environments typically include four machines, a CTM with
four tools and an automated tool changer (ATC), as well as AGVs and tool transporters (TT). This end has a station for loading and
unloading cargo. Each machine centre has a buffer storage area where work may be held before and after processing. The raw
materials are stored in an automated storage and retrieval system (AS/RS). From the beginning of a concept design to when it's put
into practice, it's important to have good operations management, logistics, and project management. Manufacturing strategies,
logistics system architecture, performance and evaluation, operation management techniques, risk assessment, and scenario analysis
are all taken into consideration when designing complex Manufacturing Systems and Flexible Manufacturing Systems (FMS),
according to Doumeingts (1987), Vallespir (1987), and Darracar (1987) [1]. Conceptual Design is the first step in the design
process, and it involves jotting down your goals and the steps necessary to get there. Writing down the details of what you'll be
modelling is also a good idea. Designing an FMS must follow strict guidelines regarding the manufacturing process, product
specifications and resources used. Various methods and techniques for making FMS have been discussed by others. To describe
FMS's formalism, Kamble and Hebbal (2010) used the IDEF family of modelling languages. Based on the functional modelling
language, Structured Analysis and Design Technique, these languages are available [2]. Additionally, there are the formalisms of
GERAM (Generalized Enterprise Reference Architecture and Methodology), CIMOSA, GERAM, GRAI/GIM (CIM Open Systems
Architecture), and the Object Flow Diagram.
Computer simulation, in particular Discrete Event Simulation (DES), is the most general method for simulating the design of
production systems (Chryssolouris, 2005) [3]. DES's key benefit is the capacity to conduct tests that cannot be carried out on actual
industrial systems. It is also possible to gather knowledge and experience that might lead to improvements in the real system, such
as detecting a bottleneck via the use of a simulation model. ARENA, Enterprise Dynamics, FlexSim, and Plant Simulation are just a
few of the DES software products devoted to manufacturing system modelling. The technique for modelling and simulation (Fig. 1)
involves an examination of the actual issue followed by conceptual design and model synthesis and an experiment to test the
solution.
Making a clear distinction between humanly controlled and automated or robotized production systems, for example, is a major
challenge at the design stage of the manufacturing systems. It is thus important to create an early design technique that can
accurately measure the productivity gains associated with improvements in production systems, such as the use of industrial robots
to replace human operators. Actually, millions of industrial robots are now in use across the globe, particularly for repetitive and
high-precision jobs such as welding [4].
©IJRASET: All Rights are Reserved | SJ Impact Factor 7.538 | ISRA Journal Impact Factor 7.894 | 2117
International Journal for Research in Applied Science & Engineering Technology (IJRASET)
ISSN: 2321-9653; IC Value: 45.98; SJ Impact Factor: 7.538
Volume 10 Issue III Mar 2022- Available at www.ijraset.com
Industrial robots have arms that resemble human arms and are capable of doing a wide range of difficult tasks much like humans. As
a result, they don't grow bored or weary of their work. Companies have seen productivity rise by 30%, manufacturing costs fall by
50%, and the utilisation of production resources rise by over 85% as a consequence of robotization. To be lucrative, industrial robots
must be used under particular circumstances, such as high production levels, repetitive labour, and precise jobs, as well as health
and safety measures at the workplace. Those circumstances are prevalent in the automobile sector, where the majority of robots are
employed" [5].
A related issue concerns the factors that should be taken into consideration while assessing the difficulty of this topic. This has to do
with the way people and machines interact. Because of our uniqueness and the wide range of our behaviours, it is impossible to
account for all the human elements that influence our decisions [6]. Other elements that must be considered include: the
dependability and performance of the machine; the maintenance of the machine; and the failures of the machine [7]. FMS also has
to integrate the transportation, storage, and quality control systems.
Consider a tiny production system with CNC machine tools that can be operated by humans or robots as an example of a conceptual
design. Two machining procedures on big and heavy objects need the use of robots because of their difficulty in handling [8]. The
Enterprise Dynamics programme was used to simulate the cell's production flow and internal logistic procedures, allowing for the
simulation and visualisation of discrete production processes. Simulated experiments are used to compare two different models [9].
A direct computation of the OEE (Overall Equipment Effectiveness) indicator is possible since the models were created taking into
consideration availability, performance, and quality factors. As part of the World Class Manufacturing process [10], OEE is one of
the most essential KPIs utilised in the automobile sector, particularly. Lean manufacturing and continuous process improvement
using standardised indicators are at the heart of WCM's philosophy [11]. An OEE indicator may be used to compare one
manufacturing system to another, and it is highly recommended for usage in large-scale production [12].
II. DESCRIPTION OF THE ISSUE
Materials handling in the production process necessitate the use of several specialized machinery and humans or robots. Loading
and unloading items from the machine and moving them to the next manufacturing step are typically the responsibilities of an
operator. Compared to human operators, industrial robots can do this task more quickly and reliably. Sector of the automobile Two
people or two robots are required to operate the four CNC lathe machines in the production system. Each operator is responsible for
two machines at once. All of a part family's components need to be rotated on their two opposite sides, which require two separate
processes (sleeves and wheels). Robots are selected since the pieces are huge and heavy. What will happen if we use industrial
robots instead of human operators? What can we do to increase our productivity? Robot motion planning strategies have been
described by a number of authors. Based on MTM (Method Time Measurement) or the classic time study approach, these
methodologies may be used to compare the capacities of robots and humans. It is also possible to employ a specific computer
programme for robot movement planning. It is possible to compare human and robot performance using the time values generated
by each approach [13]. Despite the fact that automated manufacturing lines are very efficient, problems may still emerge. If even
one of the line's components fails, the production process comes to a grinding stop. A manufacturing system's components are
crucial to its productivity because of this. Manufacturing System Performance Indicators Key performance indicators (KPIs) may be
used to assess the performance of manufacturing systems. Production capacity and Lead time for manufacturing (MLT), For ready
components, the typical wait time. The total number of items in the output queue A project is currently being worked on (WIP), It
measures the overall efficiency of a piece of equipment.
Productivity may be measured as the ratio of how long it takes to perform a given job in ideal circumstances to how long it takes in
real life, as well as the number of items that can be produced in real life vs the number of products that can be produced in perfect
conditions. As a result of certain random disturbances, such as human mistakes, it is usually impossible to create perfect
circumstances and performance is dropped below 100%.
Performance = (2)
The quality of a product may be determined by dividing the total number of items by the number of high-quality products.
Quality = (4)
A normal distribution with a sigma standard deviation may be used to explain the distribution of high-quality items. The standard
deviation may be used to define acceptable quality levels. Three sigmas is deemed enough in typical manufacturing processes.
©IJRASET: All Rights are Reserved | SJ Impact Factor 7.538 | ISRA Journal Impact Factor 7.894 | 2118
International Journal for Research in Applied Science & Engineering Technology (IJRASET)
ISSN: 2321-9653; IC Value: 45.98; SJ Impact Factor: 7.538
Volume 10 Issue III Mar 2022- Available at www.ijraset.com
There is, however, a level of 5-6 sigma that may be achieved in today's production processes, which indicates that only three faults
are feasible out of a million possibilities. It was then determined that our production system had an OEE (Overall Equipment
Effectiveness) that was comparable to that of other similar manufacturing systems. Consistency and Reliability in Machine
Operations Reliability and failures due to chance have a large role in availability.
The possibility that a thing, such as a machine, will function successfully for a certain period of time is what is meant by its
dependability.
It is difficult to foresee machine failures in the industrial setting, hence we are employing a computer simulation for future study, as
described by. Different failure characteristics for machines, robots, and human operators may be used to build a model of the
production line. As a point of comparison, here is a We utilised Enterprise Dynamics software to model and simulate discrete
manufacturing processes including robots and human resources in order to better understand the issue at hand. Manufacturing
systems that can be controlled by humans or robots have been modelled, taking into account scheduled downtime and failure rates.
For example, the models built comprise input (Source), output (Good parts) and control components for high-quality goods (Bad
parts) as well as machines, human resources, and robots in storage buffers (Queue) (Availability Control, Schedule, MTBF, MTTR).
A. Problem Formulation
To store things in FMS, most people use CTM. It moves the right tool from the central tool magazine to the machine that is doing
the job. To cut down on the cost of tooling, CTM cuts down on the number of tools needed in the system. The next parts give an
explanation of the problem and the assumptions and rules that underlie it.
B. Problem Definition
Assume the CTM has to be used for the processing of 'n' tasks J1,J2,...,Jn, and each job is processed by'm' machines
(M1,M2,...,Mm). By using heuristic techniques, the ideal sequence for combining tasks, machines, and tools is to be discovered in
order to reduce the makespan. To construct optimum schedules, the jaya algorithm is applied in this study. A comparison is made
between the suggested met heuristics and the results obtained using the techniques described in [4]. Using the example issue
provided in table 1, the jobs, machines, and tools that make up a task set 2 are examined. It is expected that the system has four
machines and four tools in order to complete the six jobs in the second set of tasks. It's easy to see that task 1 requires M1, T3, and
10 units of processing time by referring to M1-T3[10]. Machine and tool restrictions dictate the sequence of tasks that must be
proposed in order to reduce the make span. A choice on the machine and tool to use for each work must be made during scheduling.
Both the machine and CTM will keep a running list of requests for work that has yet to be completed. To keep things moving as
quickly as possible, it's imperative that the correct task be assigned to the request. As a result, the overall amount of time spent on
each task is minimised.
C. Fms Environment
FMS environments typically include four machines, a CTM with four tools and an automated tool changer (ATC), as well as AGVs
and tool transporters (TT). This end has a station for loading and unloading cargo. Each machine centre has a buffer storage area
where work may be held before and after processing. The raw materials are stored in an automated storage and retrieval system
(AS/RS).
D. Methodology and Work
The Jaya method is another strong method for finding the best answer to any kind of problem without having to think about any
parameters. People and how many generations it takes to control them are the only things you need to know in this method, just like
the TLBO method. In order to get around a problem, the JAYA algorithm thinks of new ways to do things. To use the JAYA
algorithm, there is only one step.
This makes it easier to use on a wide range of different problems. First, the population size and number of runs must be set as a
control parameter. Then, for each population, the best and worst solutions must be found. An important part of the algorithm is to
figure out which results are best and which are worst for the specific goal function and issue that are being minimised or maximised.
This leads to a change in the answer. Two random numbers, r1 and r2, have a value between 0 and 1. They can be any number
between 0 and 1.
©IJRASET: All Rights are Reserved | SJ Impact Factor 7.538 | ISRA Journal Impact Factor 7.894 | 2119
International Journal for Research in Applied Science & Engineering Technology (IJRASET)
ISSN: 2321-9653; IC Value: 45.98; SJ Impact Factor: 7.538
Volume 10 Issue III Mar 2022- Available at www.ijraset.com
III. RESULTS AND DISCUSSION
The presented algorithms have been used to schedule tasks, machines, and tools in the FMS in order to reduce the make span.
Appendix 1 contains the data for all 22 task sets analysed in the paper. Job sets with a range of jobs, machines, and tools, as well as
their processing times, have been taken into account to see how well the different approaches work. Details about each work set,
like how many jobs there are and how many operations each job can do. The machines and equipment used for each job and how
many operations each job can do are also shown. Each job set needs four machines and four tools except for task sets 21 and 22,
which don't. When you compare job set 22 to work set 21, it has eight machines and eight tools. A job set can have as many as 20
jobs in it. This means that the least number of jobs in a job set is five. This is the number of times each job set is done. It ranges
from 13 to 151, depending on which job set it is (for job set 22). In this study, a new goal function was created that looked at the
previous AIS method's best sequences and came up with pans that were the same as the ones shown [4].Table 4.2 shows that the
suggested approaches yielded sequences with better pans than [4]. As a result, the present approaches give only local optimum
solutions, but the suggested methods provide global or near-optimal answers.
For each of the 22 task sets, the minimal make span is shown, and the suggested approaches have outperformed all other methods.
The suggested approaches exhibit a significant improvement in makes span over previous methods. For the vast majority of jobs,
progress has been made. In comparison to the best available approaches, the Jaya algorithm provides 44.2 percent and 45.19 percent
gains in make span for task sets 22 and 21, respectively. For work set 22, the Jaya algorithm provides a 68.54 percent increase in
make span over the worst make span of current techniques. For job set 21, the Jaya algorithm provides a 63.58 percent improvement
over the worst make span of existing methods. The total number of operations for work set 21 is 110, while the total number of
operations for job set 22 is 151. The recommended approaches have been shown to be more effective in solving situations that
involve a high number of tasks and procedures. No improvement was found for seven job sets, five job sets (job sets 4, 13, 17, 21,
and 22), and three work sets (job sets 2, 11, and 15) where the suggested approach's percentage improvement over the best make
span of the present method exceeded 10%.
IV. CONCLUSIONS
Using the suggested approach, tasks, tools, and machines may all be scheduled. When it comes to minimising make span, the
suggested approach surpasses the current techniques. There are 22 task sets in the proposed method that demonstrate its robustness.
If you take into account the time it takes for a task to transit between computers, you may perform even more work.
