**Overview** - This PR implements a utility function `get_shared_param_info_to_lca()` that returns a `Dict[SharedParamInfo, nn.Module]` mapping `SharedParamInfo` (representing a shared parameter) to its lowest common ancestor (LCA) module. - This function can be used as a subroutine for assigning shared parameters to their LCA modules during FSDP initialization (for the composable code path in the short term). **Details** The implementation follows a simple version of [Tarjan's offline LCA algorithm](https://en.wikipedia.org/wiki/Tarjan%27s_off-line_lowest_common_ancestors_algorithm) that is based on a union-find data structure. We can use this algorithm because the set of LCA queries is fixed a priori (i.e. this is offline). Each module represents a vertex in the module tree, where there is a directed edge from parent module to child module (i.e. `p` is a parent of `c` if `c` is returned from `p.children()`). The LCA module `lca` of two modules `a` and `b` is the lowest (i.e. greatest depth) module that includes both `a` and `b` in its subtree. For the unit test, here is a visualization of the module tree:  [ghstack-poisoned]
awgu
pushed a commit
to awgu/pytorch
that referenced
this pull request
Feb 13, 2023
ghstack-source-id: a3e61ab Pull Request resolved: pytorch#94197
awgu
pushed a commit
to awgu/pytorch
that referenced
this pull request
Apr 3, 2023
ghstack-source-id: a3e61ab Pull Request resolved: pytorch#94197
Contributor
|
Looks like this PR hasn't been updated in a while so we're going to go ahead and mark this as |
Sign up for free
to join this conversation on GitHub.
Already have an account?
Sign in to comment
Add this suggestion to a batch that can be applied as a single commit.
This suggestion is invalid because no changes were made to the code.
Suggestions cannot be applied while the pull request is closed.
Suggestions cannot be applied while viewing a subset of changes.
Only one suggestion per line can be applied in a batch.
Add this suggestion to a batch that can be applied as a single commit.
Applying suggestions on deleted lines is not supported.
You must change the existing code in this line in order to create a valid suggestion.
Outdated suggestions cannot be applied.
This suggestion has been applied or marked resolved.
Suggestions cannot be applied from pending reviews.
Suggestions cannot be applied on multi-line comments.
Suggestions cannot be applied while the pull request is queued to merge.
Suggestion cannot be applied right now. Please check back later.
Stack from ghstack:
fully_shard#94198 [FSDP][3/N] Add LCA logic tofully_shardOverview
get_shared_param_info_to_lca()that returns aDict[SharedParamInfo, nn.Module]mappingSharedParamInfo(representing a shared parameter) to its lowest common ancestor (LCA) module.Details
The implementation follows a simple version of Tarjan's offline LCA algorithm that is based on a union-find data structure. We can use this algorithm because the set of LCA queries is fixed a priori (i.e. this is offline).
Each module represents a vertex in the module tree, where there is a directed edge from parent module to child module (i.e.
pis a parent ofcifcis returned fromp.children()). The LCA modulelcaof two modulesaandbis the lowest (i.e. greatest depth) module that includes bothaandbin its subtree.For the unit test, here is a visualization of the module tree:
